Basic Info
- Model Name: SH5
- Mainset / Subwoofer Color: Dark Silver
- Matching TV Size (2016 TV): 43" or above
Sound System
- Channel: 2.1 ch Speaker System
Output Power
- Total: 320W
- Sound Bar: 60W x 2 (Tweeter x 2)
- Subwoofer: 200W(Wireless)
Connectivity
- Bluetooth: 4.0
- USB: 1
- HDMI Input: 1 (HDMI 1.4, HDCP 1.4)
- HDMI Output: 1 (HDMI 1.4, HDCP 1.4)
- Audio Input: 1 (3.5mm)
- Optical: 1
Display
Sound Mode
- Sound Effect: Adapt via Sound Control (Default) / Standard / Cinema
- User EQ: Yes
- Night Mode: Yes
- Auto Sound Engine: Yes
- Auto Volume Leveler: Yes
Convenience
- OS Support: Window / Mac / iOS / Android
- Mobile Device App: Android / iOS
- Control with TV Remote: Yes
- LG Sound Sync: Bluetooth (LG TV) / Optical
- Automatic Power on/off: Bluetooth (LG TV) / Optical
- SIMPLINK: Yes
- 3D Video Signal Pass Through: Yes
- Audio Return Channel (ARC): Yes
Audio Format
- LPCM: Yes
- Dolby Digital: Yes
- FLAC: Yes (Up to 192kHz)
- OGG: Yes (Up to 48kHz)
- WAV: Yes
- MP3: Yes
- WMA: Yes
Power Consumption
- Sound Bar: 22W
- - Standby: Less than 0.5W
- Subwoofer: 33W
- - Standby: Less than 0.5W
Dimension (W x H x D)(mm)
- Sound Bar (without foot): 945 x 53 x 85
- Subwoofer: 171 x 320 x 252
Weight (kg)
- Sound Bar: 2.6
- Subwoofer: 4.2
